28BYJ-48 Driver Module ULN2003

A fritzing part for the 28BYJ-48 Driver Module ULN2003 with its JST connector and all the control and power pins. Includes also the schematic symbol and the pcb footprint.

28BYJ-48-driver

Have a look at the 28BYJ-48 Stepper Motor part also.

NOTES

  • The JST connector pins are incorrectly marked as female on purpose, as a trick to help Fritzing connect the 28BYJ-48 Unipolar Stepper Motor to it more naturally (the same trick is applied to the motor itself).

  • Used some of the fritzing tools by @Vanepp: go check them.
